Makes 🢒 Buick 🢒 2005 🢒 LaCrosse 🢒 Transmission/Transaxle 🢒 Automatic Transaxle - 4T65-E 🢒 Power Door Systems Component Views
Figure 1:

Driver Door
Object Number: 1507640 Size: LF
(1)Door Frame
(2)Outside Rearview Mirror - Driver
(3)Door Lock / Window Switch - Driver
(4)Outside Rearview Mirror Switch
(5)Window Motor - Driver
(6)Inflatable Restraint Side Impact Sensor - Left (AY1)
(7)Door Lock - Driver
Figure 2:

Passenger Door
Object Number: 1507641 Size: LF
(1)Outside Rearview Mirror - Front Passenger
(2)Door Frame
(3)Door Lock - Front Passenger
(4)Inflatable Restraint Side Impact Sensor - Right (AY1)
(5)Door Lock Switch - Front Passenger
(6)Window Switch - Front Passenger
(7)Window Motor - Front Passenger
Figure 3:

LR Door
Object Number: 1507642 Size: LF
(1)Door Frame
(2)Window Switch - LR
(3)Window Motor - LR
(4)Door Lock - LR
Figure 4:

RR Door
Object Number: 1507643 Size: LF
(1)Window Switch - RR
(2)Door Frame
(3)Door Lock - RR
(4)Window Motor - RR
