| (1) | Oil Level Indicator
Tube Bolt |
| (2) | Oil Level Indicator Tube |
| (3) | Fuel Pump Cover Opening Bolt |
| (4) | Fuel Pump Opening Cover |
| (5) | Fuel Pump Opening Cover Gasket |
| (6) | Piston Pin |
| (7) | Connecting Rod
Bolt |
| (8) | Piston Rings |
| (9) | Piston |
| (10) | Connecting Rod |
| (11) | Connecting Rod Bolt |
| (12) | Connecting Rod Bearing |
| (13) | Connecting Rod Cap |
| (14) | Connecting Rod Cap Nut |
| (15) | Oil Pressure
Sensor Fitting |
| (16) | Oil Pressure and Fuel Pump Switch Sensor |
| (17) | Engine Block |
| (18) | Camshaft Rear Bearing Hole Plug |
| (19) | Transmission
Bell Housing Locator Pin |
| (20) | Engine Block Coolant Drain Plug |
| (21) | Engine Flywheel Bolt |
| (22) | Automatic Transmission
Engine Flywheel |
| (23) | Crankshaft Rear Oil Seal |
| (24) | Crankshaft Rear Oil Seal Housing Nut |
| (25) | Crankshaft Rear
Oil Seal Housing Stud |
| (26) | Crankshaft Rear Oil Seal Housing Stud |
| (27) | Crankshaft |
| (28) | Crankshaft Rear Bearing Cap |
| (29) | Oil Pump Drive
Shaft |
| (30) | Oil Pump Drive Shaft Retainer |
| (31) | Oil Pump Locator Pin |
| (32) | Oil Pump |
| (33) | Oil Deflector |
| (34) | Oil Pump Bolt |
| (35) | Oil Pan Nut |
| (36) | Oil Pan Drain
Plug Gasket |
| (37) | Oil Pan Drain Plug Bolt |
| (38) | Oil Pan Bolt |
| (39) | Oil Pan Reinforcement |
| (40) | Oil Pan |
| (41) | Oil Pan Gasket |
| (42) | Oil
Deflector Nut |
| (43) | Oil Pump Screen |
| (44) | Crankshaft Bearing Cap Stud |
| (45) | Crankshaft Bearing Cap Bolt |
| (46) | Crankshaft Bearing
Cap |
| (47) | Crankshaft Position Sensor Reluctor Ring |
| (48) | Crankshaft Sprocket |
| (49) | Crankshaft Key |
| (50) | Crankshaft Bearing |
| (51) | Crankshaft Rear Oil Seal
Housing Locator Pin |
| (52) | Crankshaft Rear Oil Seal Housing Gasket |
| (53) | Crankshaft Rear Oil Seal Housing |
| (54) | Crankshaft
Rear Oil Seal Housing Bolt |
| (55) | Expansion Plug |
| (56) | Oil Gallery Plug |
| (57) | Camshaft |
| (58) | Camshaft Retainer |
| (59) | Camshaft Retainer Bolt |
| (60) | Camshaft
Bearings |
| (61) | Camshaft Sprocket |
| (62) | Water Pump Gasket |
| (63) | Water Pump Bolt |
| (64) | Water Pump |
| (65) | Camshaft Sprocket Bolt |
| (66) | Crankshaft Position Sensor |
| (67) | Crankshaft Balancer
Weight |
| (68) | Crankshaft Balancer Bolt |
| (69) | Crankshaft Balancer Bolt Washer |
| (70) | Crankshaft Balancer |
| (71) | Crankshaft Front Oil Seal |
| (72) | Engine
Front Cover |
| (73) | Timing Chain |
