| (1) | Engine Flywheel (Manual Transmission) |
| (2) | Engine Flywheel (Automatic Transmission) |
| (3) | Engine Flywheel Bolt |
| (4) | Oil Pan Gasket |
| (5) | Oil Pan |
| (6) | Oil Pan Cover Gasket |
| (7) | Oil Temperature Sensor |
| (8) | Oil Pan Cover |
| (9) | Oil Pan
Cover Bolt |
| (10) | Oil Pan Closeout Cover Bolt (Left Side) |
| (11) | Oil Pan
Closeout Cover |
| (12) | Oil Filter Adapter |
| (13) | Oil Filter |
| (14) | Oil Level Sensor |
| (15) | Oil Pan Closeout
Cover (Right Side) |
| (16) | Oil Pan Closeout Cover Bolt (Right Side) |
| (17) | Crankshaft
Bearing Cap Side Bolt |
| (18) | Crankshaft Bearing Caps |
| (19) | Crankshaft Bearing Cap Studs |
| (20) | Crankshaft Bearing Cap Bolts |
| (21) | Crankshaft Bearing |
| (22) | Crankshaft Thrust Bearing |
| (23) | Crankshaft |
| (24) | Crankshaft Sprocket Key |
| (25) | Engine Block Front Oil Gallery Plug |
| (26) | Clutch
Pilot Bearing (Manual Transmission) |
| (27) | Oil Pump Screen Bolt |
| (28) | Oil Pump Screen |
| (29) | Oil Pump Screen Nut |
| (30) | Oil Pump Screen O-ring Seal |
| (31) | Camshaft Position
Sensor Bolt |
| (32) | Camshaft Position Sensor |
| (33) | Oil Pressure Sensor |
| (34) | Engine Block |
| (35) | Piston Rings |
| (36) | Piston and Connecting Rod Assembly |
| (37) | Connecting
Rod Bearings |
| (38) | Connecting Rod Bearing Cap |
| (39) | Connecting Rod Bolt |
| (40) | Crankshaft
Oil Deflector |
| (41) | Balance Weight (Manual Transmission) |
