Notice: Refer to Fastener Notice in the Preface section.

Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .

Preliminary Procedures

1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle.
2. Remove the wheel. Refer to Tire and Wheel Removal and Installation.

1

Rear Shock Absorber Bolt

Tip
Support the rear axle with a jack stand before removing the shock absorber bolt.

Tighten
90 N·m (66 lb in)

2

Rear Coil Spring

Tip
Lower the jack stand to release the tension on the rear spring.
